IPS-304-ON-P12-VI-S4 Download PDF
Category: 3wire DC 4pin connector NPN inductive sensor
| Product Code | IPS-304-ON-P12-VI-S4 |
|---|---|
| housing | 12mm dia. PA or PP |
| number of wires | 3 |
| switching distance | 4 mm |
| temperature range | -20~+60 °C |
| influence protection | IP66 |
| output | 4Pin SOCKET |
| output stage | NPN TRANSISTOR |
| output function | NO |
| voltage range | 10-60VDC |
| max output current | 450 |
| max output frequency | 1500 Hz |
| indicator led | ✔ |
| max drop voltage | 2 V |
| max noload or leakage current | 15 mA |
| pressure rate | 3 bar |
| mounting | non flush (unshielded) |
| revers voltage protection | yes |
| short circuit protection | yes |
| pick voltage protection | yes |
